Yamaha Yzf R1s 2017

Yamaha Yzf R1s 2017

Yamaha YZF-1000 R1

Make Model

Yamaha YZF 1000 R1

Year

2017

Engine

Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.

Capacity

998 cc / 60.9 cu-in
Bore x Stroke

79.0  x 50.9 mm

Compression Ratio

13.0:1

Cooling System Liquid cooled
Lubrication Wet sump
Engine Management YCC-T, YCC-I, PWR, TCS, LCS, LIF, SCS, QSS, CCU & SCU

Induction

Fuel Injection with YCC-T and YCC-I

Ignition

TCI: Transistor Controlled Ignition

Starting Electric

Max Power

147.1 kW / 200.0 PS @ 13500 rpm

Max Torque

112.4 Nm / 11.5 kg-m  @ 11500 rpm
Clutch Wet, Multiple Disc

Transmission

6-speed w/multiplate slipper clutch
Final Drive "O" ring chain

Front Suspension

43mm KYB� inverted fork; fully adjustable
Front Wheel Travel 120 mm  /  4.7 in

Rear Suspension

KYB� Single shock w/piggyback reservoir, 4-way adjustable
Rear Wheel Travel 120 mm  /  4.7 in

Front Brakes

2x 320mm discs 4 piston calipers, UBS ABS

Rear Brakes

Single 220mm disc 1 piston caliper, UBS ABS

Front Tyre

120/70 ZR17

Rear Tyre

190/55 ZR17

Dimensions Length 2054.8 mm / 80.9 in
Width 690 mm / 27.2 in
Height 1150 mm / 45.3 in
Wheelbase 1419 mm / 55.9 in
Ground Clearance 135mm /  5.3 in
Seat Height 830 mm / 32.7 in

Wet Weight

199 kg / 439 lbs

Fuel Capacity

17 Liters / 4.5 US gal

The thrilling R1 blurs the line between daily rides and track days. The YZF-R1 is packed with MotoGP Championship technology: high-output, crossplane-crankshaft, 998cc engine, advanced Rider Active electronics, cutting edge suspension and more.

MotoGP, the highest form of motorcycle racing, is our proving ground. The technology Yamaha has pioneered and proven on MotoGP circuits around the world can now be enjoyed by racers and riders alike. The R1 provides riders with a taste of what it would be like to ride the championship winning Yamaha M1. A showcase of Yamaha�s technology leadership, the R1 raises the bar with its uncompromised performance and handling.

Power

By reducing frictional losses, using high tech, lightweight components and optimizing intake efficiency the R1 engine offers significant power and torque. And with a comprehensive list of electronic control technologies, the light, compact R1 is easier to control than ever.

Technology

The R1 is Yamaha�s technology flagship. From titanium rods to magnesium wheels to a whole host of electronic �Yamaha Ride Controls�, the R1 exemplifies Yamaha�s leadership role in motorcycle development and highlights our innovation, quality and attention to detail.

Features

  • Cutting-edge MotoGP�-Derived Crossplane Crankshaft Engine
    The YZF-R1� features a lightweight and compact crossplane-crankshaft, inline-four-cylinder, 998cc high output engine. Featuring titanium fracture-split connecting rods�the first ever for a production motorcycle�the motor delivers extremely high horsepower and a strong pulse of linear torque for outstanding performance.

  • Class-leading Electronics Package
    The YZF-R1 features the most advanced MotoGP�-inspired electronics package ever offered on a supersport machine: a full suite of inter-related technologies, enabling the rider to enjoy the fullest range of performance with great comfort, control, and ease of operation.

  • MotoGP�-level Controllability
    Featuring the first six-axis Inertial Measurement Unit (IMU) ever offered on a street-going motorcycle, the 2016 R1 represents the dawn of a new digital era where all riders can experience total 3D controllability.

  • Informed Systems
    IMU consists of a gyro sensor that measures pitch, roll, and yaw, as well as an accelerometer, or G-sensor, that measures acceleration in the fore-aft, up-down, and right-left directions� all at a rate of 125 calculations per second. By calculating each signal, the IMU finds the precise vehicle position and movement, and communicates it to the ECU, enabling it to control the bike�s systems.

  • Digital Rider Aids
    The YZF-R1 is fully equipped with banking-sensitive Traction Control, as well as Slide Control, Wheel Lift Control, Quickshifter, Launch Control, ABS, a Unified Braking System, and much more. The all-new R1 gives street riders, track day participants, and full-on racers an unmatched and unprecedented level of rider-adaptive performance.

  • Deltabox� Frame
    Advanced aluminum Deltabox� frame uses the engine as a stressed member of the chassis and is designed to provide optimum longitudinal, lateral and torsional rigidity balance.

  • Titanium Exhaust System
    A lightweight and free-flowing exhaust system with titanium headers and muffler canister features a mid-ship layout, positioned low and in the middle of the chassis for improved mass centralization.

  • MotoGP� Styling
    The styling on the new R1 is inspired by the YZR-M1, purposely sculpted for maximum aerodynamic efficiency.

Yamaha Yzf R1s 2017

Source: https://www.motorcyclespecs.co.za/model/yamaha/yamaha_r1%2017.htm
